The Stanley TP08 Hydraulic Trash Pump is a lightweight, heavy duty pump capable of pumping high volumes of water, sand slurries, gravel, sludge and solids up to 3 in./75 mm in diameter. The TP08 is submersible, self priming and can run dry without damage to the motor, bearings or impeller.

The TP08 has been designed to get the most from an HTMA Type II hydraulic circuit. Using only 9 gpm/34 lpm of hydraulic flow, the TP08 will pump over 800 gpm/3,028 lpm at a 10 ft/2.54 m head. The free-flow impeller and 4 in./ 100 mm inlet and outlet combine to make the TP08 one of the most efficient pumps in the business.

Weighing only 59 lbs/27 kg and with its convenient handle, the TP08 can easily be handled by one operator. The TP08 and the Stanley HP28 Power Unit make a powerful, portable team for high volume de-watering and trash pump applications.

The heavy-duty construction of the TP08 features a fabricated, all steel volute and abrasion resistant cast iron impeller. The volute uses replaceable UHMW polyeth-ylene wear plates to reduce wear and extend pump life. The heavy-duty Stanley HYREVZ™ hydraulic motor is self-lubricating.

Video

Features:

(+) Durable cast iron impeller and steel bowl

(+) Submersible (no priming required)

(+) Able to run dry without damage

(+) 4 inch discharge

(+) Lifting eyes
